MERCURY 175HP

Description

HP/kW @ Prop	175/168
Max RPM (WOT)	5000-5800
Cylinders / Configuration	V6 [64 degree] with 24-valve Dual Overhead Cam [DOHC]
Displacement (CID/Liters)	3.4L/209
Bore x Stroke (mm/in)	3.6 x 3.4 / 92 x 86
Induction System	Performance-Tuned Long-Runner Intake Manifold
Ignition	SmartCraft PCM 112 Digital Inductive
Fuel System	Electronic Fuel Injection [EFI] with ARO
Alternator Amp/Watt	85 amp / 1071 watt belt-driven [Idle Charge]
Midsection Design	Centralized Motor Mounts
Starting	SmartCraft Electric [turn-key] with SmartStart Protection
Gearcase / Ratio	4.8″ 1.85:1 [RH/LH]
Gear Shift	Electronically-Actuated Shifting
Controls	Mechanical Control with Digital Throttle and Shift [DTS]
Steering	Hydraulic [Optional] Power Steering Kit [Optional] Bit Tiller Handle Kit [Optional]
Mounting Centers	Minimum 26-inch (660 mm) Centers
Engine Protection System	SmartCraft Engine Guardian
Recommended Oil	NMMA Certified FCW SAE 10W-30
Oil Capacity	7.0 qts / 6.6 L
Fuel Requirements	Unleaded Regular 87 Octane Minimum [R+M/2] Or 91 RON 10% Ethanol Maximum
Dry Weight (lbs/kg)	473/213 *lightest model available.
Trim Range	20 degree (-6 to 14 degrees)
Tilt Range	20 degree (-6 to 14 degrees)
Shaft Length inches (mm)	20 (508) 25 (635)
Operator Warning System	SmartCraft Engine Guardian
Colors	Phantom Black

Horsepower	120 HP – 200 HP
Motor Brands	Mercury
